STYLE MC 1000 CNC milling machine

The STYLE MC series are the right machining centers for the demanding machine operators. Machining centers are known for their wide working range and versatility when it comes to machining parts. These machining centers are suitable for single pieces and small series. The STYLE MC 1000 is a CNC controlled machine with a very accessible operation and always a good view of the drawing and product.

Any questions or would you like more information about this milling machine?

We are happy to support you!

STYLE MC 1000 CNC milling machine, the machining center for the demanding machine tool

STYLE MC 1000 machining center at a glance:

  • Class C3 prestressed ball screws prevent thermal expansion for high milling accuracy
  • The X / Y / Z axis is driven directly by the axis motors, which ensures high positioning
  • Stroke X-axis: 1000 mm, Stroke Y-axis: 560 mm, Stroke Z-axis: 550 mm
  • Table size 1200 x 520 mm
  • 12000 rpm at 22 kW

The machining center with very accessible controls

The STYLE MC 1000 machining center is equipped with a very stable cast iron frame with linear guides. The machine was built and designed by real Dutch machine builders. The machining center MC series is a line of closed, compact milling machines with an X stroke of 1000 mm respectively, a modern CNC machine for the production and flexible machining of parts. The control system offers novice machineries the accessibility to get started with just a few hours of training and the experienced operator the tools to make high-quality complex products.

Programming from the office
You can place all your programs that you want to mill on a USB stick, but it is also possible to place the computer of the milling machine in your network. This allows you to program your programs outside the machine.

detail MC 1000
Machine STYLE MC 1000
X axis movement mm 1000 (1500)
Y axis movement mm 510
Z axis movement mm 510
T-slots mm 18 x 150
Max. table load kg 600
Height work table mm 910
Distance spindle nose to table mm 120 – 630
Distance spindle nose to column mm 625
hoofdspindel mc 350
Main spindle STYLE MC 1000
Main motor power kW 11
Max. rpm rpm 10000
Spindle taper (BBT/BT) 40
hoofdspindel mc 350
detail MC 1000
X-, Y- en Z-axis STYLE MC 1000
Rapid movement m/min 24 / 24 / 24
Feed rate mm/min 12 / 12 / 12
Pressure X-, Y- en Z-axis (nom/max) kN 9.6 / 19.3
Wisselaar mc 350 freesbank
Toolchanger STYLE MC 1000
Automatic toolchanger # 20
Wisselaar mc 350 freesbank
bewerkingscentrum detail
General STYLE MC 1000
Weight kg 6000 (6600)
Machine dimensions (l/w/h) m 3.0 (4.0) x 2.6 x 2.6
Work space m 4.2 (5.2) x 3.6
