The STYLE BT series consists of six models of milling machines, with a number of models available for a fully enclosed machine. The BT 2000 is a true powerhouse. The simple control makes operations such as planning and drilling possible in a few clicks. Complex operations such as dimensional milling, working with a 4th A-axis and programming with G codes are also extremely simple. These milling machines are designed and developed especially for the production of custom work and small series.
Any questions or would you like more information about this CNC milling machines?
We are happy to support you!
Erwin Koelewijn
Sales North and East Netherlands
Michel Haaima
Sales Central and West Netherlands
STYLE BT 2000 CNC milling machine, the best of STYLE in one large milling machine
STYLE BT 2000 freesbank at a glance:
- Cast iron frame cast in one piece for high loads
- Accessible controls Stroke X / Y 2000 x 800 mm
- Table load up to 2000 kg
- Maximum speed 12000 rpm
- Fully Dutch development and production
STYLE BT 2000 milling machine with the shortest changeover times
The STYLE BT 2000 makes CNC milling and drilling very cost-effective, even for single pieces and small series. Programming is incredibly fast and simple, resulting in the shortest possible changeover times. Due to the heavy stable bed, generously dimensioned clamping table and large working range over the X, Y and Z axis, the machines offer optimum flexibility for a variety of workpieces, from simple to very complex designs.
Programming from the office
You can place all your programs that you want to mill on a USB stick, but it is also possible to place the computer of the milling machine in your network. This allows you to program your programs outside the machine.
| Machine | BT 2000 | |
|---|---|---|
| X-axis movement | mm | 2000 |
| Y-axis movement | mm | 800 |
| Z-axis movement | mm | 7001 / 8002 |
| Bed width | mm | 1250 |
| Dimensions work table | mm | 2200 x 600 |
| Maximum table load | kg | 1500 / 2000 |
| Height work table | mm | 900 |
| Distance spindle nose to table | mm | 120 – 820 |
| Distance spindle nose to column | mm | 880 |
1 Spindle taper 40, 2 Spindle taper 50
| Main spindle | BT 2000 | |
|---|---|---|
| Main motor power (S6) | kW | 11 / 15 / 18.5 / 22 / 26 |
| Maximum spindle speed | rpm | 6000 – 120001 |
| 6000 – 80002 | ||
| Spindle taper | BT – SK/DIN698713 | 40 / 50 |
1 Spindle taper 40, 2 Spindle taper 50, 3 Choose for a BT or SK/DIN69871 spindle taper
| X-, Y- and Z- axis | BT 2000 | |
|---|---|---|
| Rapid movement | m/min | 8 |
| Feed rate | m/min | 4 |
| Tool changer | BT 2000 | |
|---|---|---|
| Automatic tool changer | # | 246 |
6 Choice of vertical / horizontal
| General | BT 2000 | |
|---|---|---|
| Weight | kg | 85001 / 125002 |
| Machine dimensions (l/w/h) | m | 3.8 x 3.0 x 2.9 |
1 Spindle taper 40, 2 Spindle taper 50
| Options | BT 2000 |
|---|---|
| Sheet metal | open / semi / closed |
| Integrated 4th axis | option |
| Coolant through the spindle | option |
